Power 13,8V @ 2 Ohms (Stereo): 4 x 100 WRMS
Power 13,8V @ 4 Ohms(Bridge): 2 x 200 WRMS
Minimum Impedance Output (Stereo): 2 OHMS
Minimum Impedance Output (Bridge): 4 OHMS
Input Impedance: 20K OHMS
Minimum Input Sensitivity:
Total Harmonic Distortion
(THD +N 1W @ 4Ω): < 0,01%
Signal to Noise Ratio: 90dB
Resp. Frequency (-3dB) @ 2 Ohms: 10Hz ~ 24KHz
Crossover High Pass (H.P.F.): 90Hz
Crossover Low Pass (L.P.F.): 90Hz
Bass Boost Fixo (L.P.F.): 14dB @ 45Hz
